TTX18 dampers 18mm piston provides optimal small bump sensitivity
15 clicks of low speed compression and low speed rebound
5 clicks of high-speed compression
Twin piston, three chamber air spring system, isolated from the upper tubes to reduced head build up
Total Tune Spring Curve System (TTSC) allowing total air spring tuning from the initial movement through to the bottom out
74mm post-mount disc brake mount
20x110mm DH Boost thru-axle
Max tire size: 29x2.8 inch or 27.5x3.0 inch
E-Bike approved
(CROWN NOT INCLUDED)| model | DH Air, Coil |
| wheel size | 27.5"/29" |
| steerer (stem/race) | steerer and crown sold separately |
| offset | 46-58mm |
| travel | 200mm |
| spring type | coil |
| brake mount | disc only (74mm post mount) |
| dropout | 20x110mm Boost |
| weight | 2715g (without crowns and steer tube) |
| color | black |
